Ubiquiti ES-24-250W Description:

Ubiquiti Managed PoE+ Giga Sw

HP

Ubiquiti Managed PoE+ Giga Sw
  • Non-Blocking Throughput Switching Performance
  • Gigabit Ethernet RJ45 and SFP+/SFP Ports
  • Auto-Sensing IEEE 802.3af/at PoE


Advanced Switching Technology for the Masses
Build and expand your network with Ubiquiti Networks® EdgeSwitch™, part of the EdgeMAX® line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.

The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Switching Performance
The EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

For its total, non-blocking throughput, the 24-port models support up to 26 Gbps, while the 48-port models support up to 70 Gbps.

PoE+ Flexibility
The EdgeSwitch models are available with 24 or 48 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V Passive PoE to simplify your infrastructure.

By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V Passive PoE devices, manually enable 24V passive PoE using the EdgeSwitch Configuration
Interface.

Fiber Connectivity
The EdgeSwitch provides fiber connectivity options for your growing networks. The 24-port models include two SFP ports, providing up to 1 Gbps uplinks.

For high-capacity uplinks, the 48-port models include two SFP and two SFP+ ports, providing up to 10 Gbps uplinks.

Comprehensive User Interface
Designed for convenient management, the EdgeSwitch Configuration Interface allows administrators to configure and monitor switch features in a graphical user interface.

For advanced users, an industry-standard command-line interface (CLI) is available through telnet and SSH.

Powerful Functionality
The EdgeSwitch uses a sophisticated operating system that provides basic switching features, PoE configuration per port, and a variety of advanced features including:

  • MSTP/RSTP/STP
  • VLAN, Private VLAN, Voice VLAN
  • Link Aggregation
  • DHCP Snooping, IGMP Snooping
  • TACACS+, RADIUS, 802.1X, MAC Filtering, ACL
  • DiffServ, CoS
  • Static Routing, Policy-Based Routing



Ubiquiti ES-24-250W Specifications:

General Information
Manufacturer Ubiquiti Networks, Inc
Manufacturer Part Number ES-24-250W
Manufacturer Website Address http://www.ubnt.com
Brand Name Ubiquiti
Product Line EdgeSwitch
Product Model ES-24-250W
Product Name EdgeSwitch ES-24-250W Layer 3 Switch
Product Type Layer 3 Switch
Interfaces/Ports
Total Number of Network Ports 24
Uplink Port Yes
Stack Port No
Port/Expansion Slot Details
  • 24 x Gigabit Ethernet Network
  • 2 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported Twisted Pair
Ethernet Technology Gigabit Ethernet
Network Technology
  • 10/100/1000Base-T
  • 1000Base-X
I/O Expansions
Number of Total Expansion Slots 2
Expansion Slot Type SFP
Shared SFP Slot No
Number of SFP Slots 2
Network & Communication
Layer Supported 3
Management & Protocols
Manageable Yes
Power Description
PoE (RJ-45) Port No
Power Source Power Supply
Redundant Power Supply Supported No
Physical Characteristics
Compatible Rack Unit 1U
Form Factor
  • Desktop
  • Rack-mountable
Height 44.5 mm
Width 485 mm
Depth 285.6 mm
Weight (Approximate) 3.70 kg
